Belzona 5231
SG Laminate
Slip Resistant Epoxy Floor Coating
A 2-part epoxy floor coating with non-slip aggregate that delivers excellent chemical and abrasion resistance, fast cure, and a seamless finish for industrial and commercial floor protection.
- SeriesBelzona 5000 Series
- Documents5
Overview of Belzona 5231
Belzona 5231 (SG Laminate) is a 2-part epoxy coating for floor protection that provides excellent chemical and abrasion resistance, with a durable non-slip aggregate built into the system.
This 100% solids material can be easily mixed and applied by roller on a range of rigid surfaces including concrete and steel, and reduces downtime due to its fast-curing properties.
Belzona 5231 is available in light gray, gray, or bright yellow for improved safety in potentially dangerous areas. Thanks to its low odor, it is well suited to environments such as hospitals, schools, kitchens, and production facilities.
Typical applications include workshops, industrial and storage facilities, stairs, manufacturing plants, bridges, chemical storage, and secondary containment areas.
Key Benefits
Offering outstanding chemical and abrasion resistance, this system protects floors for the long-term.
Belzona 5231 provides a seamless, slip-resistant solution that can reduce slips further by incorporating aggregate, available in bright colors for visibility.
Offering outstanding chemical and abrasion resistance, this system protects floors for the long-term.
Belzona 5231 is a fast-curing system which allows light pedestrian traffic after four hours, reducing downtime.
This solvent-free system is easy to mix and apply by roller, without the need for hot work or specialist tools.
Suitable for both pedestrian and vehicular traffic, providing durable floor protection in mixed-use industrial environments.
Application Areas
What this product handles, grouped by equipment area — each links to the full application.
Floor Problem Areas
3 applications- Slip-resistance in floors, stairs, walkwaysOSHA's slip-resistance threshold for walking surfaces is a SCOF of 0.5, and process spills, oil tracking, and worn aggregate quickly drop the working surface below that…Learn more
- Stairs, walkwaysStair tread nosings wear faster than the rest of the surface because every footfall concentrates load on the leading edge, and replacement-grade stair refinishing usuall…Learn more
- Structural walkway coatingElevated walkways and process-platform decks lose integrity at expansion joints and around penetrations, where standing water finds the substrate and freeze-thaw loosens…Learn more
Technical Data
Mechanical Properties
- Shore D Hardness (ASTM D2240)
- 78
- Barcol Hardness (ASTM D2583)
- 87
- Koenig Pendulum (ISO 1522)
- 87 seconds
- Compressive Strength @ 24 hr (ASTM D695)
- 11,147 psi (76.9 MPa)
- Compressive Strength @ 5 d
- 12,142 psi (83.7 MPa)
- Tensile Shear (ASTM D1002)
- 2,040 psi (14.06 MPa)
Adhesion (ASTM D4541 Pull-Off)
- Grit Blasted Steel
- 3,270 psi (22.55 MPa)
- Ground Steel
- 3,510 psi (24.20 MPa)
- Dry Concrete
- 1,050 psi (7.24 MPa)
- Damp Concrete
- 770 psi (5.31 MPa)
- Dry Brick
- 1,250 psi (8.62 MPa)
- Dry Quarry Tile
- 2,580 psi (17.78 MPa)
Slip Resistance (ASTM E303 Pendulum)
- As supplied — Average PTV (Wet)
- 33
- As supplied — Average PTV (Dry)
- 81
- With 30% Belzona 9221 aggregate (Wet)
- 40
- With 30% Belzona 9221 aggregate (Dry)
- 82
Abrasion & Heat Resistance
- Taber Abrasion (CS17, 1 kg, dry)
- 21 mm³ loss per 1,000 cycles
- Heat Distortion (ASTM D648, 7-day ambient cure)
- 90°F (32°C)
- Heat Distortion (post-cured 4 hr at 212°F)
- 113°F (45°C)
- Degradation Temp (DSC, ISO 11357)
- 320°F (160°C)
- Suitable down to
- -40°F (-40°C)
Working Life (from start of mixing)
- At 50°F (10°C)
- 60 minutes
- At 68°F (20°C)
- 60 minutes
- At 86°F (30°C)
- 30 minutes
Curing Time
At 50°F (10°C)
- Light pedestrian traffic
- 10 hours
- Full traffic or loading
- 24 hours
- Chemical contact
- 7 days
At 68°F (20°C)
- Light pedestrian traffic
- 5 hours
- Full traffic or loading
- 10 hours
- Chemical contact
- 5 days
At 86°F (30°C)
- Light pedestrian traffic
- 3 hours
- Full traffic or loading
- 5 hours
- Chemical contact
- 3 days
Overcoating Window
- At 68°F (20°C)
- Touch dry in 4 hours, max overcoat time 8 hours
- At 50°F (10°C)
- Touch dry in 8 hours, max overcoat time 24 hours
Service Temperature Limits
- Application temperature minimum
- 41°F (5°C)
- Heat distortion (ambient cure)
- 90°F (32°C)
- Heat distortion (post-cured)
- 113°F (45°C)
- Suitable continuous service down to
- -40°F (-40°C)
- Degradation temperature
- 320°F (160°C)
- Surface temperature during curing
- Must remain at 41°F (5°C) or above
Mixing & Application
Product PDFs
Gallery
Videos
Frequently Asked Questions
What surfaces can Belzona 5231 be applied to?
Belzona 5231 is designed for application to a range of rigid substrates including concrete, steel, and other suitable surfaces. New concrete should be allowed to cure for a minimum of 28 days, and laitance must be removed prior to application. The substrate must be clean, firm, and dry.
What is the cure schedule for Belzona 5231?
At 68°F (20°C), Belzona 5231 supports light pedestrian traffic in 5 hours, full traffic or loading in 10 hours, and chemical contact in 5 days. At 50°F (10°C) those times extend to 10 hours, 24 hours, and 7 days respectively. The product should not be applied below 41°F (5°C).
What is the slip resistance of Belzona 5231?
As supplied with the standard aggregate, Belzona 5231 achieves an average PTV of 33 wet and 81 dry when tested in accordance with ASTM E303. Slip resistance can be further improved by incorporating additional anti-slip aggregate such as Belzona 9221, with PTV values rising to 40 wet and 82 dry, exceeding the safety standard minimum PTV of 36.
