Belzona 1151
Smoothing Metal
A metal repair composite for rebuilding pitting and metal loss caused by erosion and corrosion.
A 2-part epoxy-based repair composite for rebuilding shallow pitting in metals damaged by erosion and corrosion.
- SeriesBelzona 1000 Series
- Documents5
Overview of Belzona 1151
A 2-part epoxy-based repair composite for rebuilding shallow pitting in metals damaged by erosion and corrosion. This 100% solids material is specifically formulated to easily fill in areas of metal loss up to 6 mm deep, quickly restoring large areas and avoiding hot work and plate welding. Belzona 1151 (Smoothing Metal) will not corrode and will resist a wide range of chemicals.
This repair composite is ideally suited to be overcoated with epoxy coatings such as Belzona 1321 (Ceramic S-Metal) for long-term protection against the effects of erosion, corrosion and chemical attack.
Key Benefits
Quickly restore large pitted areas in one operation
Bonds strongly to virtually any rigid surface
Engineered to withstand demanding mechanical loads
Protects against erosion and corrosive attack
Application Areas
What this product handles, grouped by equipment area — each links to the full application.
Valves, Pipes & Fittings
5 applications- Flange sealing & repairSealing of joints and flangesLearn more
- Shimming & equipment reseatingShimming and reseating of irregular equipmentLearn more
- Crack & hole repair on casings & equipmentRepair of cracks and holes on engine and pump casings, pipes, tanks and other equipmentLearn more
- Structural metal bondingHigh strength structural adhesive for metal bondingLearn more
- Shaft & hydraulic ram repairRepair of damaged shafts and hydraulic ramsLearn more
Gaskets, Seals & Shims
1 applicationTechnical Data
Mechanical Properties
- Compressive Strength (68°F cure)
- 18,097 psi (124.8 MPa)
- Compressive Strength (212°F cure)
- 21,052 psi (145.2 MPa)
- Compressive Modulus (68°F cure)
- 2.16 × 10⁵ psi (1,488 MPa)
- Tensile Strength (68°F cure)
- 6,203 psi (42.77 MPa)
- Tensile Strength (212°F cure)
- 6,836 psi (47.13 MPa)
- Young's Modulus (68°F cure)
- 0.93 × 10⁶ psi (6,412 MPa)
- Elongation (68°F cure)
- 1.08%
- Shore D Hardness (68°F cure)
- 88
- Barcol Hardness 935 (68°F cure)
- 86
- Impact Resistance (Izod, reverse notched, 68°F cure)
- 65.5 J/m
- Impact Resistance (Izod, un-notched, 68°F cure)
- 67.5 J/m
Adhesion
- Tensile Shear, Mild Steel
- 2,800 psi (19.3 MPa)
Heat & Environmental Resistance
- Heat Distortion Temperature (68°F cure)
- 111°F (44°C)
- Heat Distortion Temperature (140°F post cure)
- 189°F (87°C)
- Dry Heat Resistance
- 392°F (200°C)
- Salt Spray Resistance
- 5,000 hours, no visible corrosion
Abrasion Resistance
- CS17 Wheels (Dry)
- 27 mm³ loss per 1,000 cycles
- H10 Wheels (Wet)
- 802 mm³ loss per 1,000 cycles
Working Life
- 77°F (25°C)
- 30 minutes
Curing Time
Cure times will vary depending on ambient conditions and will be reduced for thicker sections and extended for thinner applications.
At 41°F (5°C)
- Overcoating
- 5 hours
- Machining and/or light loading
- 18 hours
- Full mechanical or thermal loading
- 7 days
At 59°F (15°C)
- Overcoating
- 3½ hours
- Machining and/or light loading
- 9 hours
- Full mechanical or thermal loading
- 2 days
At 77°F (25°C)
- Overcoating
- 2½ hours
- Machining and/or light loading
- 4½ hours
- Full mechanical or thermal loading
- 24 hours
Service Temperature Limits
- Lower temperature limit
- -40°C (-40°F)
- Upper temperature limit (dry)
- 75°C (167°F)
- Upper temperature limit (wet)
- 60°C (140°F)
Mixing & Application
Product PDFs
Videos
Frequently Asked Questions
What is Belzona 1151 used for?
Belzona 1151 is a high temperature metal-filled epoxy paste used for in-situ repair of high temperature metal substrates. It is suitable for emergency leak sealing, rebuilding pump casings, valves, flanges, heat exchanger tube sheets, and similar equipment where service temperatures exceed the limits of standard repair composites.
What service temperature can Belzona 1151 handle?
Belzona 1151 is designed for elevated temperature service, with dry service ratings substantially above standard 1000-series composites. Refer to the Product Specification Sheet for exact wet and dry service limits.
How is Belzona 1151 mixed and applied?
Belzona 1151 is a 2-part paste system. Mix the Base and Solidifier thoroughly to a uniform color, then apply with a plastic applicator or spatula directly to the prepared surface. Press firmly to displace air and ensure full contact, then contour to the desired profile. Surface preparation by abrasive blasting is strongly recommended for maximum adhesion.
