Belzona 1392
Ceramic HT2
High temperature acid-resistant coating for continuous immersion in acid-contaminated water and hydrocarbon systems.
A 2-part acid-resistant high temperature coating for erosion-corrosion protection in acid-contaminated systems up to 120°C (248°F).
- SeriesBelzona 1000 Series
- Documents6
Overview of Belzona 1392
A two-component high temperature coating system specifically designed to provide erosion-corrosion protection in acid contaminated water and hydrocarbon systems. Belzona 1392 (Ceramic HT2) is resistant to water, aqueous solutions and hydrocarbons up to a temperature of 248°F (120°C) in continuous immersion.
This high-temperature coating exhibits excellent chemical resistance, particularly in systems contaminated by acid, and provides excellent erosion resistance. It also has excellent resistance to process chemicals and conditions such as steam-out and rapid depressurisation.
Key Benefits
Outstanding performance under elevated temperature conditions including dry heat and steam exposure
Excellent resistance to a wide range of chemicals including aqueous solutions, hydrocarbons, and process chemicals
Easy to mix and apply without specialist tools
100% solids formulation reduces health and safety risks in confined spaces with no shrinkage on cure
Exceptional compressive strength for load-bearing applications and demanding mechanical environments
Application Areas
What this product handles, grouped by equipment area — each links to the full application.
Separators
5 applications- Condensate tanks & extraction pumpsBoiler feed water systems and condensate tanksLearn more
- Evaporators, de-aerators & autoclavesDe-aerators and evaporatorsLearn more
- Heat exchangers & condensersStorage tanks and condensersLearn more
- Oil/gas & water separatorsSeparators and slug catchersLearn more
- Scrubbers & absorber towersAbsorbers and scrubbersLearn more
Technical Data
Mechanical Properties
- Compressive Strength (68°F cure)
- 12,217 psi (84.2 MPa)
- Compressive Strength (212°F cure)
- 19,680 psi (135.7 MPa)
- Compressive Modulus
- 2.55 × 10⁵ psi (1,758 MPa)
- Tensile Strength (68°F cure)
- 4,866 psi (33.55 MPa)
- Tensile Strength (212°F cure)
- 5,852 psi (40.35 MPa)
- Young's Modulus (68°F)
- 9.81 × 10⁵ psi (6,764 MPa)
- Flexural Strength (68°F)
- 7,560 psi (52.12 MPa)
- Shore D Hardness (68°F)
- 84
- Shore D Hardness (212°F)
- 87
- Impact Resistance (Izod, reverse notched, 68°F)
- 60.9 J/m
Adhesion
- Tensile Shear (Grit Blasted Steel, 68°F)
- 2,630 psi (18.13 MPa)
- Tensile Shear (Grit Blasted Steel, 212°F)
- 2,530 psi (17.44 MPa)
- Pull-Off Adhesion (Grit Blasted Steel, 68°F)
- 2,720 psi (18.75 MPa)
- Pull-Off Adhesion (Grit Blasted Steel, 212°F)
- 3,690 psi (25.44 MPa)
- Cathodic Disbondment (194°F)
- 0.541 inch (13.75 mm) average radius
Heat & Environmental Resistance
- Heat Distortion Temperature (68°F cure)
- 118°F (49°C)
- Heat Distortion Temperature (212°F cure)
- 257°F (125°C)
- Heat Distortion Temperature (356°F cure)
- 390°F (199°C)
- Dry Heat Resistance
- 446°F (230°C)
- Wet Heat Resistance
- 248°F (120°C) continuous immersion
- Steam-out Resistance
- 96 hours at 410°F (210°C)
- Acid Resistance
- No rusting or blistering after 12 months in 5% sulfuric or hydrochloric acid at 194°F (90°C)
Abrasion Resistance
- H10 Wheels (Wet, 212°F cure)
- 145 mm³ loss per 1,000 cycles
Working Life
- 68°F (20°C)
- 35 minutes
Cure Times by Temperature
At 68°F (20°C)
- Time until inspection
- 12 hours
- Time until full service
- 96 hours
- Dry post cure (if required)
- 12 hours
- Wet post cure (if required)
- 28 hours
At 86°F (30°C)
- Time until inspection
- 5 hours
- Time until full service
- 18 hours
- Dry post cure (if required)
- 5 hours
- Wet post cure (if required)
- 8 hours
At 104°F (40°C)
- Time until inspection
- 3 hours
- Time until full service
- 10 hours
- Dry post cure (if required)
- 3 hours
- Wet post cure (if required)
- 5 hours
Service Temperature Limits
- Lower temperature limit
- -40°C (-40°F)
- Upper temperature limit (dry)
- 230°C (446°F)
- Upper temperature limit (wet)
- 120°C (248°F) continuous immersion
Mixing & Application
Product PDFs
Gallery
Videos
Frequently Asked Questions
What is Belzona 1392 used for?
Belzona 1392 is a 2-part epoxy coating system providing high temperature corrosion protection for metal substrates. It is used on heat exchanger tube sheets, vessel internals, separators, and similar process equipment exposed to corrosive media at elevated temperatures.
What temperatures does Belzona 1392 handle?
Belzona 1392 is designed for high temperature service in both wet and dry conditions. Specific upper service temperature limits depend on the operating environment and the chemicals present — refer to the Product Specification Sheet and Chemical Resistance Chart for detailed data.
How is Belzona 1392 applied?
Belzona 1392 is brush-applied in two coats over an abrasive-blasted substrate. Application thickness, working life, and overcoat windows must be observed in accordance with the Instructions for Use to ensure proper film build and cure.
